Voice Calls with SwiftUI and Agora

Khalea B.

Khalea B. / May 21, 2021

12 min read

iPhone with Clubhouse app. Photo by William Krause on Unsplash.

Intro

We’re going to put together a basic audio call application with Agora and SwiftUI. Upon completion, you’ll be able to join and chat in an audio channel.

This tutorial largely follows the same format as the UIKit tutorial provided by Agora. The main difference is that we need to work with UIViewControllerRepresentable in order to interface the UIKit-based UIViewController with SwiftUI.

Prerequisites

Step 1: Project Setup

Xcode Setup

Create a project by selecting iOS > App in the Xcode template menu. Set the project options to the following:

iPhone with Clubhouse app. Photo by William Krause on Unsplash.

Adding Mic Permissions

In Xcode, open the Project Settings and go to the Info tab:

iPhone with Clubhouse app. Photo by William Krause on Unsplash.

On the Custom iOS Target Properties submenu, hover over one of the keys and click the plus sign (+) to add a new property. Enter Privacy  —  Microphone Usage Description as the key. For the value, provide a reason for requesting mic access, such as "For calls or interactive live streaming.”

Installing the Agora Voice SDK

There are two ways to do this : You can either use CocoaPods or download the Agora SDK and add it to your project manually. For the sake of brevity, I will link directly to those instructions:

Initializing Agora

First, we're going to lay the groundwork for calls by implementing the AgoraRtcKit library. This will provide us with the functions necessary for connecting to and disconnecting from an Agora audio channel.

Step 2: The AgoraViewController

Start by creating a new Swift file called AgoraViewController. In this file, you'll import the AgoraRtcKit class and define a variable called agoraKit of optional type AgoraRtcEngineKit.

import Foundation
import AgoraRtcKit

class AgoraViewController: UIViewController {
    var agoraKit: AgoraRtcEngineKit?
    var agoraDelegate: AgoraRtcEngineDelegate?
}

Next, we’ll want to initialize AgoraRtcEngineKit. To properly do so, we’ll add two methods:  viewDidLoad() and initializeAgoraEngine(withAppId, delegate).

import Foundation
import AgoraRtcKit

class AgoraViewController: UIViewController {

    // ...

    override func viewDidLoad() {
        super.viewDidLoad()
        initializeAgoraEngine()
        joinChannel()
    }

    func initializeAgoraEngine() {
        agoraKit = AgoraRtcEngineKit.sharedEngine(withAppId: "YOUR_APP_ID", delegate: agoraDelegate)
    }
}
  • `viewDidLoad()`  is a UIKit view life cycle method that will execute included code after the related view is loaded. In this case, we will be initializing the Agora engine and joining a channel (we‘ll add this function later) after the view is loaded.
  • `initializeAgoraEngine(withAppId, delegate)` : Here, we simply create an instance of `AgoraRtcEngineKit` with your App ID and an `AgoraRtcEngineDelegate` to handle event callbacks to the application (in this case, the View Controller itself, as it is a subclass of `AgoraRtcEngineDelegate`). The delegate will know when errors occur, when someone joins a channel, and so on.

Step 3: Joining & Leaving a Channel

Channels are Agora RTC sessions that allow users to communicate with each other. Channels have UIDs (unique identifiers), names, and tokens that are requirements to join the channel. We can use the following function to join a test channel  ( make sure you replace “Token” with your own):

import Foundation
import AgoraRtcKit

class AgoraViewController: UIViewController {
    // ...

    func joinChannel() {
        agoraKit?.joinChannel(byToken: "Token", channelId: "TestChannel", info: nil, uid: 0, joinSuccess: {(channel, uid, elapsed) in})
    }
}

Note: For production apps, you should generate tokens on your own server,instead of using temporary tokens from the Agora Console. Learn more here.

In order to leave a channel, we’ll want to call an even simpler function with our agoraKit object:

import Foundation
import AgoraRtcKit

class AgoraViewController: UIViewController {
    // ...

    func leaveChannel() {
        agoraKit?.leaveChannel(nil)
    }
}

Note: Don’t worry about the leaveChannelBlock parameter. It’s an optional callback that would provide us with call stats after leaving.

After leaving the channel, we want to free up memory being used by destroying the AgoraRtcEngineKit instance as follows:

import Foundation
import AgoraRtcKit

class AgoraViewController: UIViewController {
    // ...

    func destroyInstance() {
        AgoraRtcEngineKit.destroy()
    }
}

Finally, we’ll use the viewWillDisappear life cycle function in order to call leaveChannel and destroyInstance once the user clicks the End Call button:

import Foundation
import AgoraRtcKit

class AgoraViewController: UIViewController {
    // ...

    override func viewWillDisappear(_ animated: Bool) {
        leaveChannel()
        destroyInstance()
    }
}

SwiftUI

We’ll keep it simple here with just two views: a home view that has a button allowing you to enter a call and a fullscreen sheet for the call itself, which will have Mute and End Call buttons.

Step 4: Homepage

Navigate to ContentView.swift and add a button called Join Call:

import SwiftUI

struct ContentView: View {
  var body: some View {
    Button(action: {}) {
      Text("Join Call")
        .font(.title)
        .foregroundColor(.white)
        .padding(.all)
    }
    .background(Color.green)
    .cornerRadius(8.0)
  }
}

Now, in order to have the sheet pop up over the home view, we’ll have to add a binding Boolean state variable that acts as the source of truth for whether or not we should be presenting the call sheet. Just under the struct declaration, add the following:

struct ContentView: View {
  @State private var showCall: Bool = false
  // ...
}

Now, before we add the call sheet into our main view, you’ll want to create a SwiftUI view file called CallView.swift. At first, it will only have “Hello, World” text in it.

Afterward, we can get the Join Call button from the ContentView to present the CallView like so:

struct ContentView: View {
  // ...
  var body: some View {
    Button(action: {}) {
      // ...
    }
    // ...
    .fullScreenCover(isPresented: $showCall, content: {
      CallView()
    })
  }
}

If you go to Live Preview mode in your SwiftUI preview panel, you should be able to click the button and see the new CallView pop-up!

CallView sheet opens after pressing Join Call button

Step 5: Call View

Next, we’ll want to add our Mute and End Call buttons. We’ll be using SF Symbols for the icons. We’ll nest all the elements under a VStack, and the call buttons will be nested within an HStack.

import SwiftUI

struct CallView: View {
  var body: some View {
    VStack {
      Text("Welcome to the call!")
        .bold()
      Spacer()
      HStack {
        Image(systemName: "mic.circle.fill")
          .font(.system(size:64.0))
          .foregroundColor(.blue)
          .padding()
        Spacer()
        Image(systemName: "phone.circle.fill")
          .font(.system(size:64.0))
          .foregroundColor(.red)
          .padding()
      }
      .padding()
    }
  }
}
CallView sheet opens after pressing Join Call button

At this point, we have all of the basic UI elements that we need for calls. Now we just need to implement functionality for those new buttons.

Let’s start with ending calls. When we end a call, we want the CallView to disappear. In order for this to happen, we’ll add an @Environment state variable to the CallView that keeps track of whether or not the sheet is presented:

struct CallView: View {
  @environment(\.presentationMode) var presentationMode
  var body: some View {
    // ...
  }
}

To dismiss the sheet, we will add an onTapGesture action to the phone button:

struct CallView: View {
  var body: some View {
    VStack {
      // ...
      HStack {
        // ...
        Image(systemName: "phone.circle.fill")
          .font(.system(size:64.0))
          .foregroundColor(.red)
          .padding()
          .onTapGesture {
            presentationMode.wrappedValue.dismiss()
          }
      }
      .padding()
    }
  }
}

While this will dismiss the sheet, it does not terminate the call. That’s because we haven’t yet mapped our SwiftUI code to our AgoraViewController functions.

Connecting SwiftUI & UIKit

We need to wrap our UIViewController in a SwiftUI view. This is where UIViewControllerRepresentable comes in!

Step 6: UIViewControllerRepresentable

Create a Swift file called AgoraRep.swift. Import SwiftUI at the top, and create a struct named AgoraRep that inherits from UIViewControllerRepresentable.

We’ll see some errors since we haven’t implemented the requisite makeUIViewController and updateViewController methods. Add them now:

  • updateViewController(context) : This updates the view controller with new information received from SwiftUI. We can use this to check for certain changes in the UI, and perform functions accordingly.
  • makeUIViewController(uiViewController, context): This creates a view controller of the desired type and configures its initial state. Code in this block is executed when the view controller is made.

We will return an instance of AgoraViewController that will be used in the SwiftUI:

import Foundation
import SwiftUI

struct AgoraRep: UIViewControllerRepresentable {
    func makeUIViewController(context: Context) -> some UIViewController {
        let agoraViewController = AgoraViewController()
        agoraViewController.agoraDelegate = context.coordinator
        return agoraViewController
    }

    func updateUIViewController(_ uiViewController: UIViewControllerType, context: Context) {

    }
}

Step 7: Coordinator

There will be an error for now because we do not yet have a coordinator. The coordinator is essentially what allows the UIKit-based (Agora) view controller to communicate events with SwiftUI.

Under the updateUIViewController function, create a class called Coordinator that inherits from NSObject and conforms to the AgoraRtcEngineDelegate protocol. You’ll have to import AgoraRtcKit at the top of the file as well.

Add a class variable parent of type AgoraRep. This will be used in the init function to give the coordinator a reference to the AgoraRep so it can interact with AgoraRep directly.

import AgoraRtcKit

struct AgoraRep: UIViewControllerRepresentable {
    // ...

    class Coordinator: NSObject, AgoraRtcEngineDelegate {
        var parent: AgoraRep
        init(_ agoraRep: AgoraRep) {
            parent = agoraRep
        }
    }
}

Now we need to add the mandatory makeCoordinator function. It just returns an instance of the Coordinator class and passes the AgoraRep in with it:

struct AgoraRep: UIViewControllerRepresentable {
    // ...

    class Coordinator: NSObject, AgoraRtcEngineDelegate {
        // ...
        func makeCoordinator() -> Coordinator {
            return Coordinator(self)
        }
    }
}

At this point, we should be able to make calls! All we need to do is add an instance of AgoraRep to CallView somewhere in the VStack. Its width and height will be set to 0 because we don’t need to present anything:

struct CallView: View {
    var body: some View {
        VStack {
            // ...
            AgoraRep()
                .frame(width: 0, height: 0, alignment: .center)
            // ...
        }
    }
}

Mute Input Audio

In order to mute the input audio, we want to track the status or state of the mic button, with the default state being set to unmuted. Fortunately, SwiftUI provides declarative state & data flow solutions that make this simple.

Step 8: Mute Button State

Before we do anything in the UI, we need to add a new mute function called didClickMuteButton to the AgoraViewController. We can use muteLocalAudioStream(Bool) to tell Agora whether to stop publishing the audio input on the device:

class AgoraViewController: UIViewController {
  // ...
  func didClickMuteButton(isMuted: Bool) {
    isMuted ? (agoraKit?.muteLocalAudioStream(true)) : (agoraKit?.muteLocalAudioStream(false))
  }
}

The next step is to monitor the state of the Mute button and trigger didClickMuteButton in the view controller via AgoraRep.

At the top of the body element in CallView, add a state variable of type Bool called isMuted just under the struct definition, and set it to false:

struct CallView: View {
  @State private var isMuted: Bool = false
  // ...
}

Add an onTapGesture modifier to the Image element with the mic icon that will toggle the value of isMuted and the fill color of the mic. To let the user know that they are muted, we’ll also toggle the foregroundColor from blue to yellow when the state changes:

struct CallView: View {
  // ...
  VStack {
    HStack {
      Image(systemName: "mic.circle.fill")
        ...
        .foregroundColor(isMuted ? Color.yellow : Color.blue)
        .onTapGesture {
          isMuted ? (isMuted = false) : (isMuted = true)
      }
    }
  }
}

Now we have to relay the state of the Mute button to the AgoraRep controller. First, add a private binding variable isMuted of type Bool just under the struct declaration. In the updateUIViewController function, add an if-else statement that updates uiViewController.didClickMuteButton dynamically:

struct AgoraRep: UIViewControllerRepresentable {
  @Binding var isMuted: Bool
  // ...
  func updateUIViewController(_ uiViewController: AgoraViewController, context: Context) {
    isMuted ? (uiViewController.didClickMuteButton(isMuted: true)) : (uiViewController.didClickMuteButton(isMuted: false))
  }
}

Then in the CallView you’ll want to add an argument isMuted to the AgoraRep instance and pass in the binding variable $isMuted as its value:

struct CallView: View {
  // ...
  VStack {
    // ...
    AgoraRep(isMuted: $isMuted)
      .frame(width: 0, height: 0, alignment: .center)
    // ...
  }
}

Testing Calls

There are a number of ways to test calls, but here we'll use an iOS device and the Agora WebDemo tool.

First, open the WebDemo and enter your App ID, channel name ("TestChannel"), and Temporary Token. Mute the mic on your computer if possible and click Join. Then you'll want to run the application on your iOS device and join the call from there.

Note: You may need to go to your iOS device’s Settings > General > Device Management menu and grant permissions to run apps from your development account after installation.

You can follow these steps to test the functionality:

  • Audio transmission from the iOS device: While the computer mic is muted, speak into the iOS device's microphone. Audio should come from the computer.
  • Audio transmission to the iOS device: Mute the mic on the iOS device and unmute the computer's mic. When you speak into the computer's mic, audio should come from the iOS device.

Note: Make sure you leave the call on the WebDemo site and on iOS, or else you will continue to use up free Agora credits!

Conclusion

Congrats, you’ve successfully learned to interface UIKit components with SwiftUI Views as well as the essentials of using Agora's iOS Voice SDK. The code used in this tutorial is available on Github.
